1PCS Milliohm Meter Low Resistance Tester Ohmmeter to Measure Resistance Value

In Stock. Leaves warehouse within 2 - 3 business days

$181.00 AUD
Maximum quantity available reached.
Enter NEW5 at Checkout for 5% OFF & Free Shipping Australia Wide
More detailed product descriptions
Free Shipping Australia Wide
100% Safe & Secure Checkout
100 Days Return Policy *
1 Year Warranty *

1PCS Milliohm Meter Low Resistance Tester Ohmmeter to Measure Resistance Value

Technical ParametersResistance measuring range 0.001-120 ΩResistance measuring accuracy 1 mΩ Capacitance measuring range 10pf-20000ufCapacitance measuring accuracy 1pfThis Milliohm meter is not suitable for too much high accuracy Capacitance Testing. Capacitance testing results may be NOT very accurately because of capacitors characteristics.Operating power supply 7-12VDC, recommend 9VDCOperating current <100mAOperating temperature -10 to +50℃; 85% R.H., non-condensationStorage temperature -20 to +65℃; 85% R.H., non- condensationSize 57x45x20mmTerminal DescriptionTerminal codeDescriptionVDD7-12V operating power supply +GND7-12V operating power supply-R+Connect to resistanceR-Connect to resistanceCAPConnect to Capacitance +GNDConnect to Capacitance -Button FunctionButton CodeDescriptionFUNResistance and capacitance measurement switchingMes /CalTesting meter calibration Resistance measurement calibration: Short-circuited connect resistance measuring wire, then press [Mes/Cal] button. Capacitance measurement calibration: Open-circuited connect capacitance measuring wire, then press [Mes/Cal] button. This Milliohm meter is not suitable for too much high accuracy Capacitance Testing. Capacitance testing results may be NOT very accurately because of capacitors characteristics, thanks. Milliohm Meter package including: 1 Unit x Original HR390 Milliohm Meter Low Resistance Capacitance Tester 1 Set x Alligator testing clip

Product Features

  • This Milliohm meter is not suitable for too much high accuracy Capacitance Testing. Capacitance testing results may be NOT very accurately because of capacitors characteristics.
  • Operating temperature -10 to +50C; 85% R.H., non-condensation Storage temperature -20 to +65C; 85% R.H., non-condensation
  • Resistance measuring range: 0.001-120
  • Resistance measuring accuracy: 1 m
  • Capacitance measuring range: 10pf-20000uf
