{"id":7841894957207,"title":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power","handle":"6pcs-l298n-motor-driver-board-module-dc-stepper-motor-controller-dual-h-bridge-for-smart-car-robot-power","description":"\u003ch3\u003e6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification:Module name: dual H bridge motor drive moduleWork mode: H bridge\ndrive (double road)Main control chip: L298NLogical voltage: 5VDrive voltage:\n5V-35VLogical current: 0mA-36mADriving current: 2A(MAX single bridge)Storage\ntemperature: - 20 °C to + 135 °CMaximum power: 25WWeight: 30gPeripheral\ndimensions: 434327mmPackaging: electrostatic bagNotes:1. When you are\ndriving voltage is 7V to 12V(above logo for the 12V input, which can actually\naccept input range is 7V -12V), you can enable the onboard 5V logic power\nsupply, when using the on-board 5V power supply, The interface of + 5V power\nsupplydoes not input voltage, but can draw 5V voltage for external use.2. When\nthe driving voltage is higher than 12V, it is less than or equal to 24V. for\nexample, to drive a motor with rated voltage of 18V, the jumper cap with 5V\noutput enabled on-board voltage must be pulled out and then outside the 5V\noutput port Connect 5V voltageto L298N internal logic voltage supply.Package\nIncluded:6 L298N Motor Driver controller Board Module\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eThis module USES L298N as the main drive chip, with strong driving ability, low calorific value and strong anti-interference ability.\u003c\/li\u003e\n \u003cli\u003eEasy to use, No assembly required, Just wire up motors and power. Double H bridge driver working mode make it more high efficient.\u003c\/li\u003e\n \u003cli\u003eVoltage: 5V-35V, drive current: 2A (Max single bridge). This module USES a large capacity filter capacitance, a continuation protection diode, can improve reliability.\u003c\/li\u003e\n \u003cli\u003eNote: Through this module can use the built-in 78 m05 drive power supply parts of their work, but in order to avoid the voltage regulator chip damage, when using the driving voltage is greater than 12V, please use the external power supply 5V logic.\u003c\/li\u003e\n \u003cli\u003eApplication: It is used for DIY projects, smart car robot Power and so on. Package Included:6* L298N Motor Driver controller Board Module\u003c\/li\u003e\n \u003c\/ul\u003e\n\n","published_at":"2022-11-04T06:29:28+11:00","created_at":"2022-11-04T06:29:36+11:00","vendor":"Atnsinc","type":"Single Board Computers","tags":["industrial_Oct2022"],"price":13000,"price_min":13000,"price_max":13000,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42685477191831,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B08ZKQX2N8","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power","public_title":null,"options":["Default Title"],"price":13000,"weight":160,"compare_at_price":null,"inventory_management":null,"barcode":"701715460294","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/products\/B08ZKQX2N8.jpg?v=1667523125","\/\/newnestshop.com\/cdn\/shop\/products\/71Hwduo9mTL.jpg?v=1667503776","\/\/newnestshop.com\/cdn\/shop\/products\/71PrIXIYYcL.jpg?v=1667503776","\/\/newnestshop.com\/cdn\/shop\/products\/71-x-8wPS8L.jpg?v=1667503776","\/\/newnestshop.com\/cdn\/shop\/products\/71jTbnFZFrL.jpg?v=1667503776","\/\/newnestshop.com\/cdn\/shop\/products\/71QpGZA0FZL.jpg?v=1667503776","\/\/newnestshop.com\/cdn\/shop\/products\/71i97LM-qBL.jpg?v=1667503776"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/products\/B08ZKQX2N8.jpg?v=1667523125","options":["Title"],"media":[{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30297344868503,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/B08ZKQX2N8.jpg?v=1667523125"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/B08ZKQX2N8.jpg?v=1667523125","width":1600},{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30295073816727,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/71Hwduo9mTL.jpg?v=1667503776"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/71Hwduo9mTL.jpg?v=1667503776","width":1600},{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30295073849495,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/71PrIXIYYcL.jpg?v=1667503776"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/71PrIXIYYcL.jpg?v=1667503776","width":1600},{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30295073882263,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/71-x-8wPS8L.jpg?v=1667503776"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/71-x-8wPS8L.jpg?v=1667503776","width":1600},{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30295073915031,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/71jTbnFZFrL.jpg?v=1667503776"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/71jTbnFZFrL.jpg?v=1667503776","width":1600},{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30295073947799,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/71QpGZA0FZL.jpg?v=1667503776"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/71QpGZA0FZL.jpg?v=1667503776","width":1600},{"alt":"6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power - NewNest Australia","id":30295073980567,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/newnestshop.com\/cdn\/shop\/products\/71i97LM-qBL.jpg?v=1667503776"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/products\/71i97LM-qBL.jpg?v=1667503776","width":1600}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003e6PCS L298N Motor Driver Board Module DC Stepper Motor Controller Dual H-Bridge for Smart Car Robot Power\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification:Module name: dual H bridge motor drive moduleWork mode: H bridge\ndrive (double road)Main control chip: L298NLogical voltage: 5VDrive voltage:\n5V-35VLogical current: 0mA-36mADriving current: 2A(MAX single bridge)Storage\ntemperature: - 20 °C to + 135 °CMaximum power: 25WWeight: 30gPeripheral\ndimensions: 434327mmPackaging: electrostatic bagNotes:1. When you are\ndriving voltage is 7V to 12V(above logo for the 12V input, which can actually\naccept input range is 7V -12V), you can enable the onboard 5V logic power\nsupply, when using the on-board 5V power supply, The interface of + 5V power\nsupplydoes not input voltage, but can draw 5V voltage for external use.2. When\nthe driving voltage is higher than 12V, it is less than or equal to 24V. for\nexample, to drive a motor with rated voltage of 18V, the jumper cap with 5V\noutput enabled on-board voltage must be pulled out and then outside the 5V\noutput port Connect 5V voltageto L298N internal logic voltage supply.Package\nIncluded:6 L298N Motor Driver controller Board Module\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eThis module USES L298N as the main drive chip, with strong driving ability, low calorific value and strong anti-interference ability.\u003c\/li\u003e\n \u003cli\u003eEasy to use, No assembly required, Just wire up motors and power. Double H bridge driver working mode make it more high efficient.\u003c\/li\u003e\n \u003cli\u003eVoltage: 5V-35V, drive current: 2A (Max single bridge). This module USES a large capacity filter capacitance, a continuation protection diode, can improve reliability.\u003c\/li\u003e\n \u003cli\u003eNote: Through this module can use the built-in 78 m05 drive power supply parts of their work, but in order to avoid the voltage regulator chip damage, when using the driving voltage is greater than 12V, please use the external power supply 5V logic.\u003c\/li\u003e\n \u003cli\u003eApplication: It is used for DIY projects, smart car robot Power and so on. Package Included:6* L298N Motor Driver controller Board Module\u003c\/li\u003e\n \u003c\/ul\u003e\n\n"}
