{"id":9121916878999,"title":"AS7341 Visible Spectrum Infrared Color Spectrometer Sensor Module for arduino","handle":"as7341-visible-spectrum-infrared-color-spectrometer-sensor-module-for-arduino","description":"\u003ch3\u003eAS7341 Visible Spectrum Infrared Color Spectrometer Sensor Module for arduino\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eAS7341 is an 11-channel multi-spectral sensor for color detection and spectral\nanalysis applications. The spectral response is defined in the wavelengths\nfrom approximately 350nm to 1000nm. 6 channels can be processed in parallel by\nindependent ADCs while the other channels are accessible via a multiplexer. 8\noptical channels cover the visible spectrum, one channel can be used to\nmeasure near infra-red light and one channel is a photo diode without filter\n(\"clear\"). The device also integrates a dedicated channel to detect 50Hz or\n60Hz ambient light flicker. The flicker detection engine can also buffer data\nfor calculating other flicker frequencies externally. The NIR channel in\ncombination with the other VIS channel may provide information of surrounding\nambient light conditions (light source detection). The device can also be\nsynchronized to external signals via pin GPIO. Features 8 optical channels\ndistributed over the visible range 3 extra channels: Clear, Flicker and NIR\nchannel 6 parallel ADCs for signal processing Benefits Spectral information\nenables highly accurate object color measurements Addtional spectral detection\nand characterization Optimized channel count and signal processing for fast\nmeasurements Highly compact, cost-effective packaging This product suits for\nthe following applications: Color matching and skin tone measurement Enhanced\nArtificial Intelligence: Search and shop by color (eCommerce boost) Laboratory\ncolor or reagent analysis Home or office ambient spectral sensing Spectral\npresence detection\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eAS7341 is an 11-channel multi-spectral sensor for color detection and spectral analysis applications. The spectral response is defined in the wavelengths from approximately 350nm to 1000nm. 6 channels can be processed in parallel by independent ADCs while the other channels are accessible via a multiplexer. 8 optical channels cover the visible spectrum, one channel can be used to measure near infra-red light and one channel is a photo diode without filter (\"clear\"). The device also integrat\u003c\/li\u003e\n \u003cli\u003e8 optical channels distributed over the visible range\u003c\/li\u003e\n \u003cli\u003e3 extra channels: Clear, Flicker and NIR channel\u003c\/li\u003e\n \u003cli\u003e6 parallel ADCs for signal processing\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-07-11T01:14:05+10:00","created_at":"2025-07-11T01:14:01+10:00","vendor":"GODIYMODULES","type":"Optical Sensors","tags":["industrial_best_sellers_Jun2025"],"price":13000,"price_min":13000,"price_max":13000,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45658876018839,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0DBQKDV67","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"AS7341 Visible Spectrum Infrared Color Spectrometer Sensor Module for arduino","public_title":null,"options":["Default Title"],"price":13000,"weight":14,"compare_at_price":null,"inventory_management":"shopify","barcode":"Mod-AS7341-001","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B0DBQKDV67.jpg?v=1775809390","\/\/newnestshop.com\/cdn\/shop\/files\/61BCgrgfxSL.jpg?v=1752160444","\/\/newnestshop.com\/cdn\/shop\/files\/618yDPMWFvL.jpg?v=1752160444","\/\/newnestshop.com\/cdn\/shop\/files\/61ytZ3BoKDL.jpg?v=1752160444","\/\/newnestshop.com\/cdn\/shop\/files\/61QgxPsYoCL.jpg?v=1752160444"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B0DBQKDV67.jpg?v=1775809390","options":["Title"],"media":[{"alt":null,"id":38392170643607,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B0DBQKDV67.jpg?v=1775809390"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B0DBQKDV67.jpg?v=1775809390","width":1500},{"alt":null,"id":38392170676375,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61BCgrgfxSL.jpg?v=1752160444"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61BCgrgfxSL.jpg?v=1752160444","width":1500},{"alt":null,"id":38392170709143,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/618yDPMWFvL.jpg?v=1752160444"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/618yDPMWFvL.jpg?v=1752160444","width":1500},{"alt":null,"id":38392170741911,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61ytZ3BoKDL.jpg?v=1752160444"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61ytZ3BoKDL.jpg?v=1752160444","width":1500},{"alt":null,"id":38392170774679,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61QgxPsYoCL.jpg?v=1752160444"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61QgxPsYoCL.jpg?v=1752160444","width":1500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eAS7341 Visible Spectrum Infrared Color Spectrometer Sensor Module for arduino\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eAS7341 is an 11-channel multi-spectral sensor for color detection and spectral\nanalysis applications. The spectral response is defined in the wavelengths\nfrom approximately 350nm to 1000nm. 6 channels can be processed in parallel by\nindependent ADCs while the other channels are accessible via a multiplexer. 8\noptical channels cover the visible spectrum, one channel can be used to\nmeasure near infra-red light and one channel is a photo diode without filter\n(\"clear\"). The device also integrates a dedicated channel to detect 50Hz or\n60Hz ambient light flicker. The flicker detection engine can also buffer data\nfor calculating other flicker frequencies externally. The NIR channel in\ncombination with the other VIS channel may provide information of surrounding\nambient light conditions (light source detection). The device can also be\nsynchronized to external signals via pin GPIO. Features 8 optical channels\ndistributed over the visible range 3 extra channels: Clear, Flicker and NIR\nchannel 6 parallel ADCs for signal processing Benefits Spectral information\nenables highly accurate object color measurements Addtional spectral detection\nand characterization Optimized channel count and signal processing for fast\nmeasurements Highly compact, cost-effective packaging This product suits for\nthe following applications: Color matching and skin tone measurement Enhanced\nArtificial Intelligence: Search and shop by color (eCommerce boost) Laboratory\ncolor or reagent analysis Home or office ambient spectral sensing Spectral\npresence detection\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eAS7341 is an 11-channel multi-spectral sensor for color detection and spectral analysis applications. The spectral response is defined in the wavelengths from approximately 350nm to 1000nm. 6 channels can be processed in parallel by independent ADCs while the other channels are accessible via a multiplexer. 8 optical channels cover the visible spectrum, one channel can be used to measure near infra-red light and one channel is a photo diode without filter (\"clear\"). The device also integrat\u003c\/li\u003e\n \u003cli\u003e8 optical channels distributed over the visible range\u003c\/li\u003e\n \u003cli\u003e3 extra channels: Clear, Flicker and NIR channel\u003c\/li\u003e\n \u003cli\u003e6 parallel ADCs for signal processing\u003c\/li\u003e\n \u003c\/ul\u003e"}
