{"id":8857673007255,"title":"Mitutoyo 530-114 Vernier Caliper, Stainless Steel, Inch\/Metric, 0-8\" Range, +\/-0.002\" Accuracy, 0.0078\" Resolution 0-8\" 0.0078\" +\/-0.002\"","handle":"mitutoyo-530-114-vernier-caliper-stainless-steel-inch-metric-0-8-range-0-002-accuracy-0-0078-resolution-0-8-0-0078-0-002","description":"\u003ch3\u003eMitutoyo 530-114 Vernier Caliper, Stainless Steel, Inch\/Metric, 0-8\" Range, +\/-0.002\" Accuracy, 0.0078\" Resolution\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThe Mitutoyo 530 series vernier caliper has two sets of jaws and a depth bar\nfor four-way measurement in inch and metric units of outside dimension (OD),\ninside dimension (ID), step, and depth, for applications where the highest\naccuracy is required, especially in scientific research and in industries\nwhere parts must fit exactly. The caliper has a dual vernier scale, with an\nupper scale measuring in inches and a lower scale measuring in millimeters. A\n14-degree vernier face angle improves visibility and helps prevent parallax\nerror in measurement reading. The caliper’s two sets of jaws provide the\ncapability to make OD and ID measurements, as well as step measurements, where\nthe butt end of the fixed jaw measures one end of a work piece before its\nupper\/lower or inner\/outer steps are measured. A depth measuring blade with\nrounded edges provides the ability to make depth measurements. The scales are\nraised to slide easily and protect the graduation markings. A thumbwheel\npermits fast and easy measuring. A clamping screw on the upper scale rotates\nto control scale movement and locks to hold the sliding jaw’s position. The\ncaliper is made of hardened, corrosion-resistant stainless steel with a satin\nchrome finish that helps reduce glare. The caliper meets Federal Accuracy\nSpecifications GGG-C-111B.Calipers measure the distance between two opposing\nsides of an object. They make inside, outside, depth, or step measurements,\naccording to their type. Calipers are commonly used in architecture,\nmetalworking, mechanical engineering, and machining. The simplest calipers\nhave two legs to mark the two points and require a ruler to take the\nmeasurement. More complex calipers use two sets of jaws instead of legs and\nhave up to two graduated scales. Vernier, dial, and digital calipers give\ndirect and accurate readings and are functionally identical, having a\ncalibrated scale with a fixed jaw, and another jaw with a movable pointer that\nslides along the scale. The vernier caliper has a scale sliding parallel to\nthe main scale for an additional, fractional reading to improve measurement\nprecision. The dial caliper has a circular dial with a pointer on a toothed\ngear rack replacing the second vernier scale. As with the vernier, this second\nmeasurement is added to the reading from the main scale to obtain the result.\nThe digital caliper takes a differential by zeroing the display at any point\nalong the slide, with an LCD that displays a single value in English and\/or\nmetric units. Mitutoyo manufactures precision measuring tools, metrology\nequipment, and systems. The company was founded in Tokyo in 1934 and formed\nMitutoyo America Corporation in 1963, which is headquartered in Aurora, IL.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHardened stainless steel construction with satin chrome finish, for protection of caliper\u003c\/li\u003e\n \u003cli\u003eFour-way measurement capability for outside dimension (OD), inside dimension (ID), depth, and step measurements\u003c\/li\u003e\n \u003cli\u003eRaised sliding surfaces to help prevent defacement and wear of scale graduations\u003c\/li\u003e\n \u003cli\u003eModest, 14-degree face angle on vernier scale, to help improve visibility and reduce the possibility of parallax errors\u003c\/li\u003e\n \u003cli\u003eMeets Federal Accuracy Specifications GGG-C-111B\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-03-09T14:53:52+11:00","created_at":"2025-02-26T10:53:41+11:00","vendor":"Mitutoyo","type":"Digital Calipers","tags":["home_improvement_Feb2025"],"price":31600,"price_min":31600,"price_max":31600,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45226554163351,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B003UATQHK","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Mitutoyo 530-114 Vernier Caliper, Stainless Steel, Inch\/Metric, 0-8\" Range, +\/-0.002\" Accuracy, 0.0078\" Resolution 0-8\" 0.0078\" +\/-0.002\"","public_title":null,"options":["Default Title"],"price":31600,"weight":181,"compare_at_price":null,"inventory_management":"shopify","barcode":"530-114","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B003UATQHK.jpg?v=1775784404","\/\/newnestshop.com\/cdn\/shop\/files\/41N6yXD18tL.jpg?v=1740527624","\/\/newnestshop.com\/cdn\/shop\/files\/51-qCCj9xEL.jpg?v=1740527624","\/\/newnestshop.com\/cdn\/shop\/files\/41MUgv11LML.jpg?v=1740527624"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B003UATQHK.jpg?v=1775784404","options":["Title"],"media":[{"alt":null,"id":37128592359575,"position":1,"preview_image":{"aspect_ratio":3.597,"height":278,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B003UATQHK.jpg?v=1775784404"},"aspect_ratio":3.597,"height":278,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B003UATQHK.jpg?v=1775784404","width":1000},{"alt":null,"id":37128592392343,"position":2,"preview_image":{"aspect_ratio":1.634,"height":612,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/41N6yXD18tL.jpg?v=1740527624"},"aspect_ratio":1.634,"height":612,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/41N6yXD18tL.jpg?v=1740527624","width":1000},{"alt":null,"id":37128592425111,"position":3,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51-qCCj9xEL.jpg?v=1740527624"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51-qCCj9xEL.jpg?v=1740527624","width":2000},{"alt":null,"id":37128592457879,"position":4,"preview_image":{"aspect_ratio":2.488,"height":402,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/41MUgv11LML.jpg?v=1740527624"},"aspect_ratio":2.488,"height":402,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/41MUgv11LML.jpg?v=1740527624","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eMitutoyo 530-114 Vernier Caliper, Stainless Steel, Inch\/Metric, 0-8\" Range, +\/-0.002\" Accuracy, 0.0078\" Resolution\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThe Mitutoyo 530 series vernier caliper has two sets of jaws and a depth bar\nfor four-way measurement in inch and metric units of outside dimension (OD),\ninside dimension (ID), step, and depth, for applications where the highest\naccuracy is required, especially in scientific research and in industries\nwhere parts must fit exactly. The caliper has a dual vernier scale, with an\nupper scale measuring in inches and a lower scale measuring in millimeters. A\n14-degree vernier face angle improves visibility and helps prevent parallax\nerror in measurement reading. The caliper’s two sets of jaws provide the\ncapability to make OD and ID measurements, as well as step measurements, where\nthe butt end of the fixed jaw measures one end of a work piece before its\nupper\/lower or inner\/outer steps are measured. A depth measuring blade with\nrounded edges provides the ability to make depth measurements. The scales are\nraised to slide easily and protect the graduation markings. A thumbwheel\npermits fast and easy measuring. A clamping screw on the upper scale rotates\nto control scale movement and locks to hold the sliding jaw’s position. The\ncaliper is made of hardened, corrosion-resistant stainless steel with a satin\nchrome finish that helps reduce glare. The caliper meets Federal Accuracy\nSpecifications GGG-C-111B.Calipers measure the distance between two opposing\nsides of an object. They make inside, outside, depth, or step measurements,\naccording to their type. Calipers are commonly used in architecture,\nmetalworking, mechanical engineering, and machining. The simplest calipers\nhave two legs to mark the two points and require a ruler to take the\nmeasurement. More complex calipers use two sets of jaws instead of legs and\nhave up to two graduated scales. Vernier, dial, and digital calipers give\ndirect and accurate readings and are functionally identical, having a\ncalibrated scale with a fixed jaw, and another jaw with a movable pointer that\nslides along the scale. The vernier caliper has a scale sliding parallel to\nthe main scale for an additional, fractional reading to improve measurement\nprecision. The dial caliper has a circular dial with a pointer on a toothed\ngear rack replacing the second vernier scale. As with the vernier, this second\nmeasurement is added to the reading from the main scale to obtain the result.\nThe digital caliper takes a differential by zeroing the display at any point\nalong the slide, with an LCD that displays a single value in English and\/or\nmetric units. Mitutoyo manufactures precision measuring tools, metrology\nequipment, and systems. The company was founded in Tokyo in 1934 and formed\nMitutoyo America Corporation in 1963, which is headquartered in Aurora, IL.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHardened stainless steel construction with satin chrome finish, for protection of caliper\u003c\/li\u003e\n \u003cli\u003eFour-way measurement capability for outside dimension (OD), inside dimension (ID), depth, and step measurements\u003c\/li\u003e\n \u003cli\u003eRaised sliding surfaces to help prevent defacement and wear of scale graduations\u003c\/li\u003e\n \u003cli\u003eModest, 14-degree face angle on vernier scale, to help improve visibility and reduce the possibility of parallax errors\u003c\/li\u003e\n \u003cli\u003eMeets Federal Accuracy Specifications GGG-C-111B\u003c\/li\u003e\n \u003c\/ul\u003e"}
