{"id":8751929819287,"title":"NooElec SAWbird+ NOAA - Premium Saw Filter \u0026 Cascaded Ultra-Low Noise LNA Module for NOAA Applications. 137MHz Center Frequency","handle":"nooelec-sawbird-noaa-premium-saw-filter-cascaded-ultra-low-noise-lna-module-for-noaa-applications-137mhz-center-frequency","description":"\u003ch3\u003eNooElec SAWbird+ NOAA - Premium Saw Filter \u0026amp; Cascaded Ultra-Low Noise LNA Module for NOAA Applications. 137MHz Center Frequency\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFull product information can be found on the product page at nooelec.com.\nSAWbird+ NOAA is a self-contained LNA module that allows you to capture\nbeautiful weather images from NOAA satellites. It has very high attenuation\noutside the 5MHz bandpass range, centered around 137.5MHz, and a minimum gain\nof 30dB within the bandpass range. The rated current consumption is 180 mA.\nThe SAWbird+ series contains two extremely low noise LNAs arranged around a\nspecially designed high-performance SAW filter with the desired frequency.\nEach LNA module has 2 EMI shields to separate each sensitive LNA from external\ninterference. M3 mounting holes are also available to mount the PCB in your\ncustom case or project using standard hardware. Each module offers 3 different\npower options, but you should only use one power option at a time! The\nrecommended power supply via the SMA output port (for bias - T - capable SDRs\nsuch as the NESDR SMArTee) is 3V-5V DC. If you don't have a bias-T enabled\nSDR, you can also use the external power options via the micro USB port or the\npower input head (0.1\" socket). The recommended external power input is 3.3V\nto 5.5V DC. Although the SAWbird has a protection circuit for surge conditions\nand voltages of up to 12V DC should continue to work and do not damage the\ndevice, use for a longer period of time is not recommended. Conditions would\nnot fall under the standard 2 year warranty.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eSAWbird+ NOAA is a self-contained LNA module designed for capturing beautiful weather images available from NOAA satellites (~137MHz)\u003c\/li\u003e\n \u003cli\u003eThe module uses 2 ultra-low-noise LNAs and a custom high-performance SAW filter centered at the frequency of interest\u003c\/li\u003e\n \u003cli\u003eSAWbird+ NOAA can be powered in 3 ways: via bias tee, through the on-board microUSB connector, or through DC barrel connector with the included USB to DC connector adapter\u003c\/li\u003e\n \u003cli\u003eIncludes free aluminum enclosure, male SMA to male SMA adapter and USB to DC barrel connector adapter. Full 2 year warranty and support direct through Nooelec!\u003c\/li\u003e\n \u003cli\u003eFor further details, please review the product datasheet\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-01-24T11:29:11+11:00","created_at":"2025-01-24T04:43:43+11:00","vendor":"NooElec","type":"Radio Frequency Filters","tags":["industrial_best_sellers_Jan2025"],"price":21700,"price_min":21700,"price_max":21700,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45073320083607,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B07TWPR871","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"NooElec SAWbird+ NOAA - Premium Saw Filter \u0026 Cascaded Ultra-Low Noise LNA Module for NOAA Applications. 137MHz Center Frequency","public_title":null,"options":["Default Title"],"price":21700,"weight":50,"compare_at_price":null,"inventory_management":"shopify","barcode":"616469146472","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B07TWPR871.jpg?v=1737681063","\/\/newnestshop.com\/cdn\/shop\/files\/71wqLVv98WL.jpg?v=1737654226","\/\/newnestshop.com\/cdn\/shop\/files\/81MTwZGXx9L.jpg?v=1737654226","\/\/newnestshop.com\/cdn\/shop\/files\/71RCsyCzheL.jpg?v=1737654226","\/\/newnestshop.com\/cdn\/shop\/files\/71YLBVy5UwL.jpg?v=1737654226"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B07TWPR871.jpg?v=1737681063","options":["Title"],"media":[{"alt":null,"id":36797488267415,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2500,"width":2500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B07TWPR871.jpg?v=1737681063"},"aspect_ratio":1.0,"height":2500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B07TWPR871.jpg?v=1737681063","width":2500},{"alt":null,"id":36795086667927,"position":2,"preview_image":{"aspect_ratio":1.0,"height":2500,"width":2500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/71wqLVv98WL.jpg?v=1737654226"},"aspect_ratio":1.0,"height":2500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/71wqLVv98WL.jpg?v=1737654226","width":2500},{"alt":null,"id":36795086700695,"position":3,"preview_image":{"aspect_ratio":1.0,"height":2500,"width":2500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/81MTwZGXx9L.jpg?v=1737654226"},"aspect_ratio":1.0,"height":2500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/81MTwZGXx9L.jpg?v=1737654226","width":2500},{"alt":null,"id":36795086733463,"position":4,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/71RCsyCzheL.jpg?v=1737654226"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/71RCsyCzheL.jpg?v=1737654226","width":2000},{"alt":null,"id":36795086766231,"position":5,"preview_image":{"aspect_ratio":1.0,"height":2500,"width":2500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/71YLBVy5UwL.jpg?v=1737654226"},"aspect_ratio":1.0,"height":2500,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/71YLBVy5UwL.jpg?v=1737654226","width":2500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eNooElec SAWbird+ NOAA - Premium Saw Filter \u0026amp; Cascaded Ultra-Low Noise LNA Module for NOAA Applications. 137MHz Center Frequency\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eFull product information can be found on the product page at nooelec.com.\nSAWbird+ NOAA is a self-contained LNA module that allows you to capture\nbeautiful weather images from NOAA satellites. It has very high attenuation\noutside the 5MHz bandpass range, centered around 137.5MHz, and a minimum gain\nof 30dB within the bandpass range. The rated current consumption is 180 mA.\nThe SAWbird+ series contains two extremely low noise LNAs arranged around a\nspecially designed high-performance SAW filter with the desired frequency.\nEach LNA module has 2 EMI shields to separate each sensitive LNA from external\ninterference. M3 mounting holes are also available to mount the PCB in your\ncustom case or project using standard hardware. Each module offers 3 different\npower options, but you should only use one power option at a time! The\nrecommended power supply via the SMA output port (for bias - T - capable SDRs\nsuch as the NESDR SMArTee) is 3V-5V DC. If you don't have a bias-T enabled\nSDR, you can also use the external power options via the micro USB port or the\npower input head (0.1\" socket). The recommended external power input is 3.3V\nto 5.5V DC. Although the SAWbird has a protection circuit for surge conditions\nand voltages of up to 12V DC should continue to work and do not damage the\ndevice, use for a longer period of time is not recommended. Conditions would\nnot fall under the standard 2 year warranty.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eSAWbird+ NOAA is a self-contained LNA module designed for capturing beautiful weather images available from NOAA satellites (~137MHz)\u003c\/li\u003e\n \u003cli\u003eThe module uses 2 ultra-low-noise LNAs and a custom high-performance SAW filter centered at the frequency of interest\u003c\/li\u003e\n \u003cli\u003eSAWbird+ NOAA can be powered in 3 ways: via bias tee, through the on-board microUSB connector, or through DC barrel connector with the included USB to DC connector adapter\u003c\/li\u003e\n \u003cli\u003eIncludes free aluminum enclosure, male SMA to male SMA adapter and USB to DC barrel connector adapter. Full 2 year warranty and support direct through Nooelec!\u003c\/li\u003e\n \u003cli\u003eFor further details, please review the product datasheet\u003c\/li\u003e\n \u003c\/ul\u003e"}
