{"id":9680787865751,"title":"STEPPERONLINE 100:1 Planetary Gearbox Nema 11 Stepper Motor Low Speed High Torque DIY Camera","handle":"stepperonline-100-1-planetary-gearbox-nema-11-stepper-motor-low-speed-high-torque-diy-camera","description":"\u003ch3\u003eSTEPPERONLINE 100:1 Planetary Gearbox Nema 11 Stepper Motor Low Speed High Torque DIY Camera\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThis high precision NEMA 11 Stepper motor has an integrated Planetary gearbox\nwith a 99.05:1 gear ratio, the resolution reach 0.018 deg. step angle. It's a\ngood solution in applications that need very low rotation speeds and\/or lots\nof torque. Electrical Specification: Manufacturer Part Number:\n11HS20-0674S-PG100 Motor Type: Bipolar Stepper Step Angle: 0.018 deg. \nHolding Torque: 4Nm Rated Current\/phase: 0.67A Phase Resistance: 9.2ohms \nInductance: 5.7mH+\/-20%(1KHz) Gearbox Specifications: Gearbox Type:\nPlanetary Gear Ratio: 99.05:1 Gear Efficiency: 73% Backlash at No-\nload:\u0026lt;=1 deg. Max.Permissible Torque: 4Nm(566oz-in) Moment Permissible\nTorque: 6Nm(850oz-in) Shaft Maximum Axial Load: 5N Shaft Maximum Radial\nLoad: 25N Physical Specifications: Frame Size: 30 x 30mm Motor Length:\n50.5mm Gearbox Length: 42.7mm Shaft Diameter: 6mm Shaft Length: 18mm \nD-cut Length: 12mm Number of Leads: 4 Lead Length: 500mm Weight: 330g\nConnection: Black(A+), Green(A-), Red(B+), Blue(B-) Warning: Make sure the\nmotor connect to a constant current or chopper drive controller before you\ntest motor. Connecting the motor directly to a power supply will destroy the\nmotor.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHigh Torque Low Speed\u003c\/li\u003e\n \u003cli\u003e0.018 deg. Step Angle\u003c\/li\u003e\n \u003cli\u003eNEMA 11 bipolar 4-wire\u003c\/li\u003e\n \u003cli\u003ePlanetary Gearbox Ratio 99.05:1\u003c\/li\u003e\n \u003cli\u003eRated current 0.67A \u0026amp; resistance 9.2ohms\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2026-07-30T19:40:56+10:00","created_at":"2026-07-26T19:09:40+10:00","vendor":"STEPPERONLINE","type":"3D Printer Motors","tags":["home_improvement_Aug2026"],"price":23700,"price_min":23700,"price_max":23700,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48067979182231,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B00PNEQPCU","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"STEPPERONLINE 100:1 Planetary Gearbox Nema 11 Stepper Motor Low Speed High Torque DIY Camera","public_title":null,"options":["Default Title"],"price":23700,"weight":330,"compare_at_price":null,"inventory_management":"shopify","barcode":"701056329526","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEQPCU.jpg?v=1785056982","\/\/newnestshop.com\/cdn\/shop\/files\/61F6E971y7L.jpg?v=1785056982","\/\/newnestshop.com\/cdn\/shop\/files\/51YGIE2SqJL.jpg?v=1785056982","\/\/newnestshop.com\/cdn\/shop\/files\/61KFg8Jaj8L.jpg?v=1785056983","\/\/newnestshop.com\/cdn\/shop\/files\/51BhCnr_2UL.jpg?v=1785056982"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEQPCU.jpg?v=1785056982","options":["Title"],"media":[{"alt":null,"id":42455458840727,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEQPCU.jpg?v=1785056982"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEQPCU.jpg?v=1785056982","width":1000},{"alt":null,"id":42455458873495,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1100,"width":1100,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61F6E971y7L.jpg?v=1785056982"},"aspect_ratio":1.0,"height":1100,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61F6E971y7L.jpg?v=1785056982","width":1100},{"alt":null,"id":42455458906263,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51YGIE2SqJL.jpg?v=1785056982"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51YGIE2SqJL.jpg?v=1785056982","width":1000},{"alt":null,"id":42455458939031,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1100,"width":1100,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61KFg8Jaj8L.jpg?v=1785056983"},"aspect_ratio":1.0,"height":1100,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61KFg8Jaj8L.jpg?v=1785056983","width":1100},{"alt":null,"id":42455458971799,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51BhCnr_2UL.jpg?v=1785056982"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51BhCnr_2UL.jpg?v=1785056982","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eSTEPPERONLINE 100:1 Planetary Gearbox Nema 11 Stepper Motor Low Speed High Torque DIY Camera\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThis high precision NEMA 11 Stepper motor has an integrated Planetary gearbox\nwith a 99.05:1 gear ratio, the resolution reach 0.018 deg. step angle. It's a\ngood solution in applications that need very low rotation speeds and\/or lots\nof torque. Electrical Specification: Manufacturer Part Number:\n11HS20-0674S-PG100 Motor Type: Bipolar Stepper Step Angle: 0.018 deg. \nHolding Torque: 4Nm Rated Current\/phase: 0.67A Phase Resistance: 9.2ohms \nInductance: 5.7mH+\/-20%(1KHz) Gearbox Specifications: Gearbox Type:\nPlanetary Gear Ratio: 99.05:1 Gear Efficiency: 73% Backlash at No-\nload:\u0026lt;=1 deg. Max.Permissible Torque: 4Nm(566oz-in) Moment Permissible\nTorque: 6Nm(850oz-in) Shaft Maximum Axial Load: 5N Shaft Maximum Radial\nLoad: 25N Physical Specifications: Frame Size: 30 x 30mm Motor Length:\n50.5mm Gearbox Length: 42.7mm Shaft Diameter: 6mm Shaft Length: 18mm \nD-cut Length: 12mm Number of Leads: 4 Lead Length: 500mm Weight: 330g\nConnection: Black(A+), Green(A-), Red(B+), Blue(B-) Warning: Make sure the\nmotor connect to a constant current or chopper drive controller before you\ntest motor. Connecting the motor directly to a power supply will destroy the\nmotor.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHigh Torque Low Speed\u003c\/li\u003e\n \u003cli\u003e0.018 deg. Step Angle\u003c\/li\u003e\n \u003cli\u003eNEMA 11 bipolar 4-wire\u003c\/li\u003e\n \u003cli\u003ePlanetary Gearbox Ratio 99.05:1\u003c\/li\u003e\n \u003cli\u003eRated current 0.67A \u0026amp; resistance 9.2ohms\u003c\/li\u003e\n \u003c\/ul\u003e"}
