{"id":8754166759575,"title":"STEPPERONLINE 5:1 Planetary Gearbox Nema 17 Stepper Motor 0.4A for DIY CNC Robot 3D Printer","handle":"stepperonline-5-1-planetary-gearbox-nema-17-stepper-motor-0-4a-for-diy-cnc-robot-3d-printer","description":"\u003ch3\u003eSTEPPERONLINE 5:1 Planetary Gearbox Nema 17 Stepper Motor 0.4A for DIY CNC Robot 3D Printer\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThis is a short geared NEMA 17 Stepper motor, total length inlcuding shaft\nbelow 80mm, and with 6mm diameter shaft. It has an integrated planetary\ngearbox with a 5.18:1 gear ratio, the resolution reach 0.35 deg. step angle.\nIt's a good solution in applications that need very low rotation speeds and\/or\nlots of torque. Electrical Specification: Manufacturer Part Number:\n17HS13-0404S-PG5 Motor Type: Bipolar Stepper Step Angle: 0.35 deg.\nHolding Torque without Gearbox: 25Ncm(31.2oz.in) Rated Current\/phase: 0.4A\n Phase Resistance: 27ohms Inductance: 28.5mH+\/-20%(1KHz) Gearbox\nSpecifications: Gearbox Type: Planetary Gear Ratio: 5.18:1 Efficiency:\n90% Backlash at No-load: \u0026lt;=3 deg. Max.Permissible Torque: 3Nm(424.83oz.in)\n Moment Permissible Torque: 5Nm(708.06oz.in) Shaft Maximum Axial Load: 50N\n Shaft Maximum Radial Load: 100N Physical Specifications: Frame Size: 42 x\n42mm Motor Length: 34mm Gearbox Length: 27.3mm Shaft Diameter: 6mm \nShaft Length: 18mm D-cut Length: 12mm Number of Leads: 4 Lead Length:\n500mm Weight: 380g Connection: Black(A+), Green(A-), Red(B+), Blue(B-)\nWarning: Make sure the motor connect to a constant current or chopper drive\ncontroller before you test motor. Connecting the motor directly to a power\nsupply will destroy the motor.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eGood Torque Good Speed\u003c\/li\u003e\n \u003cli\u003e0.35 deg. Step Angle\u003c\/li\u003e\n \u003cli\u003eNEMA 17 bipolar 4-wire\u003c\/li\u003e\n \u003cli\u003ePlanetary Gearbox Ratio 5.18:1\u003c\/li\u003e\n \u003cli\u003eRated current 0.4A \u0026amp; resistance 27ohms\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-01-26T13:43:54+11:00","created_at":"2025-01-25T22:27:13+11:00","vendor":"STEPPERONLINE","type":"3D Printer Motors","tags":["industrial_best_sellers_Jan2025"],"price":21300,"price_min":21300,"price_max":21300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45077102592151,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B00PNER4V6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"STEPPERONLINE 5:1 Planetary Gearbox Nema 17 Stepper Motor 0.4A for DIY CNC Robot 3D Printer","public_title":null,"options":["Default Title"],"price":21300,"weight":399,"compare_at_price":null,"inventory_management":"shopify","barcode":"701056330867","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B00PNER4V6.jpg?v=1737849996","\/\/newnestshop.com\/cdn\/shop\/files\/61ewFeTuQPL.jpg?v=1737804436","\/\/newnestshop.com\/cdn\/shop\/files\/51h3QQrUr0L.jpg?v=1737804436","\/\/newnestshop.com\/cdn\/shop\/files\/61iUvdhgvxL.jpg?v=1737804435","\/\/newnestshop.com\/cdn\/shop\/files\/51-N6hD9W3L.jpg?v=1737804435","\/\/newnestshop.com\/cdn\/shop\/files\/51f2lwQpxJL.jpg?v=1737804435","\/\/newnestshop.com\/cdn\/shop\/files\/41bEioSjcpL.jpg?v=1737804435"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNER4V6.jpg?v=1737849996","options":["Title"],"media":[{"alt":null,"id":36812296814743,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNER4V6.jpg?v=1737849996"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNER4V6.jpg?v=1737849996","width":1000},{"alt":null,"id":36807567409303,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61ewFeTuQPL.jpg?v=1737804436"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61ewFeTuQPL.jpg?v=1737804436","width":1000},{"alt":null,"id":36807567442071,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51h3QQrUr0L.jpg?v=1737804436"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51h3QQrUr0L.jpg?v=1737804436","width":1000},{"alt":null,"id":36807567474839,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61iUvdhgvxL.jpg?v=1737804435"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61iUvdhgvxL.jpg?v=1737804435","width":1000},{"alt":null,"id":36807567540375,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51-N6hD9W3L.jpg?v=1737804435"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51-N6hD9W3L.jpg?v=1737804435","width":1000},{"alt":null,"id":36807567638679,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51f2lwQpxJL.jpg?v=1737804435"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51f2lwQpxJL.jpg?v=1737804435","width":1000},{"alt":null,"id":36807567704215,"position":7,"preview_image":{"aspect_ratio":2.591,"height":193,"width":500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/41bEioSjcpL.jpg?v=1737804435"},"aspect_ratio":2.591,"height":193,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/41bEioSjcpL.jpg?v=1737804435","width":500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eSTEPPERONLINE 5:1 Planetary Gearbox Nema 17 Stepper Motor 0.4A for DIY CNC Robot 3D Printer\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThis is a short geared NEMA 17 Stepper motor, total length inlcuding shaft\nbelow 80mm, and with 6mm diameter shaft. It has an integrated planetary\ngearbox with a 5.18:1 gear ratio, the resolution reach 0.35 deg. step angle.\nIt's a good solution in applications that need very low rotation speeds and\/or\nlots of torque. Electrical Specification: Manufacturer Part Number:\n17HS13-0404S-PG5 Motor Type: Bipolar Stepper Step Angle: 0.35 deg.\nHolding Torque without Gearbox: 25Ncm(31.2oz.in) Rated Current\/phase: 0.4A\n Phase Resistance: 27ohms Inductance: 28.5mH+\/-20%(1KHz) Gearbox\nSpecifications: Gearbox Type: Planetary Gear Ratio: 5.18:1 Efficiency:\n90% Backlash at No-load: \u0026lt;=3 deg. Max.Permissible Torque: 3Nm(424.83oz.in)\n Moment Permissible Torque: 5Nm(708.06oz.in) Shaft Maximum Axial Load: 50N\n Shaft Maximum Radial Load: 100N Physical Specifications: Frame Size: 42 x\n42mm Motor Length: 34mm Gearbox Length: 27.3mm Shaft Diameter: 6mm \nShaft Length: 18mm D-cut Length: 12mm Number of Leads: 4 Lead Length:\n500mm Weight: 380g Connection: Black(A+), Green(A-), Red(B+), Blue(B-)\nWarning: Make sure the motor connect to a constant current or chopper drive\ncontroller before you test motor. Connecting the motor directly to a power\nsupply will destroy the motor.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eGood Torque Good Speed\u003c\/li\u003e\n \u003cli\u003e0.35 deg. Step Angle\u003c\/li\u003e\n \u003cli\u003eNEMA 17 bipolar 4-wire\u003c\/li\u003e\n \u003cli\u003ePlanetary Gearbox Ratio 5.18:1\u003c\/li\u003e\n \u003cli\u003eRated current 0.4A \u0026amp; resistance 27ohms\u003c\/li\u003e\n \u003c\/ul\u003e"}
