STEPPERONLINE E Series Nema 17 Stepper Motor Bipolar Stepper Motor 60Ncm 2.1A Extruder Motor

This is one of strongest bipolar Nema 17 stepper motor with 1.8 deg. step angle (200 steps/revolution). Each phase draws 2.1A, allowing for a holding torque up to 60Ncm Electrical Specification: Manufacturer Part Number: 17HE24-2104S Motor Type: Bipolar Stepper Step Angle: 1.8 deg. Holding Torque: 60Ncm Rated Current/phase: 2.1A Phase Resistance: 1.7ohms Inductance: 3.1mH+/-20%(1KHz) Physical Specification: Frame Size: 42 x 42mm Body Length: 60mm Shaft Diameter: 5mm Shaft Length: 24mm D-cut Length: 15mm Number of Leads: 4 Lead Length: 500mm Weight: 500g Connection: Black(A+), Green(A-), Red(B+), Blue(B-) Warning: Make sure the motor connect to a constant current or chopper drive controller before you test motor. Connecting the motor directly to a power supply will destroy the motor.

Product Features

  • New E series Stepper Motor, Very High Torque
  • 60Ncm holding torque
  • NEMA 17 bipolar 1.65"x1.65"x2.36" 4-wire
  • 1.8 deg. step angle(200 steps/rev)
  • Rated current 2.1A & resistance 1.7ohms
