{"id":8764385296535,"title":"STEPPERONLINE Micro Stepper Motor Nema 11 Bipolar Stepping 0.67A 17oz.in\/12Ncm 1.8deg 4 Leads","handle":"stepperonline-micro-stepper-motor-nema-11-bipolar-stepping-0-67a-17oz-in-12ncm-1-8deg-4-leads","description":"\u003ch3\u003eSTEPPERONLINE Micro Stepper Motor Nema 11 Bipolar Stepping 0.67A 17oz.in\/12Ncm 1.8deg 4 Leads\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThis hybrid bipolar stepper motor with 1.8 deg. step angle (200\nsteps\/revolution). Each phase draws 670 mA at 6.2 V, allowing for a holding\ntorque of 12Ncm(17oz-in). Planetary Gearbox is available for this model.\nElectrical Specification: Manufacturer Part Number: 11HS20-0674S Motor\nType: Bipolar Stepper Step Angle: 1.8 deg. Holding Torque: 12Ncm(17oz-in)\n Rated Current\/phase: 0.67A Phase Resistance: 9.2ohms Inductance:\n5.7mH+\/-20%(1KHz) Physical Specification: Frame Size: 28 x 28mm Body\nLength: 51mm Shaft Diameter: 5mm Shaft Length: 20mm D-cut Length: 15mm \nNumber of Leads: 4 Lead Length: 500mm Weight: 190g Connection: Black(A+),\nGreen(A-), Red(B+), Blue(B-) Warning: Make sure the motor connect to a\nconstant current or chopper drive controller before you test motor. Connecting\nthe motor directly to a power supply will destroy the motor.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eNEMA 11 Hybrid bipolar stepper motor, 12Ncm(17oz-in) holding torque\u003c\/li\u003e\n \u003cli\u003eFrame Size 28 x 28mm, Body Length 51mm\u003c\/li\u003e\n \u003cli\u003e4-wires (Black, Green, Blue, Red)\u003c\/li\u003e\n \u003cli\u003eRated current 0.67A ,Step Angle 1.8, resistance 9.2ohms\u003c\/li\u003e\n \u003cli\u003eShaft Diameter 5mm , Shaft Length 20mm\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2025-01-29T12:43:32+11:00","created_at":"2025-01-28T22:07:51+11:00","vendor":"STEPPERONLINE","type":"3D Printer Motors","tags":["industrial_best_sellers_Jan2025"],"price":16900,"price_min":16900,"price_max":16900,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":45089280131223,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B00PNEPMM4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"STEPPERONLINE Micro Stepper Motor Nema 11 Bipolar Stepping 0.67A 17oz.in\/12Ncm 1.8deg 4 Leads","public_title":null,"options":["Default Title"],"price":16900,"weight":240,"compare_at_price":null,"inventory_management":"shopify","barcode":"701056319121","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEPMM4.jpg?v=1775756500","\/\/newnestshop.com\/cdn\/shop\/files\/61xyjU-qPtL.jpg?v=1738062473","\/\/newnestshop.com\/cdn\/shop\/files\/61Og7ED8x2L.jpg?v=1738062473","\/\/newnestshop.com\/cdn\/shop\/files\/61jddrCLygL.jpg?v=1738062473","\/\/newnestshop.com\/cdn\/shop\/files\/5184vJWSVwL.jpg?v=1738062473","\/\/newnestshop.com\/cdn\/shop\/files\/419QlaMYspL.jpg?v=1738062473","\/\/newnestshop.com\/cdn\/shop\/files\/31cKfwDcIqL_dda6a09e-ccc4-4250-9f41-09c8bcdbf008.jpg?v=1738062473"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEPMM4.jpg?v=1775756500","options":["Title"],"media":[{"alt":null,"id":36835386949783,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEPMM4.jpg?v=1775756500"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B00PNEPMM4.jpg?v=1775756500","width":1000},{"alt":null,"id":36835386982551,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61xyjU-qPtL.jpg?v=1738062473"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61xyjU-qPtL.jpg?v=1738062473","width":1000},{"alt":null,"id":36835387015319,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61Og7ED8x2L.jpg?v=1738062473"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61Og7ED8x2L.jpg?v=1738062473","width":1000},{"alt":null,"id":36835387048087,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/61jddrCLygL.jpg?v=1738062473"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/61jddrCLygL.jpg?v=1738062473","width":1000},{"alt":null,"id":36835387080855,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/5184vJWSVwL.jpg?v=1738062473"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/5184vJWSVwL.jpg?v=1738062473","width":1000},{"alt":null,"id":36835387113623,"position":6,"preview_image":{"aspect_ratio":2.326,"height":215,"width":500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/419QlaMYspL.jpg?v=1738062473"},"aspect_ratio":2.326,"height":215,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/419QlaMYspL.jpg?v=1738062473","width":500},{"alt":null,"id":36835387146391,"position":7,"preview_image":{"aspect_ratio":2.632,"height":190,"width":500,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/31cKfwDcIqL_dda6a09e-ccc4-4250-9f41-09c8bcdbf008.jpg?v=1738062473"},"aspect_ratio":2.632,"height":190,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/31cKfwDcIqL_dda6a09e-ccc4-4250-9f41-09c8bcdbf008.jpg?v=1738062473","width":500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eSTEPPERONLINE Micro Stepper Motor Nema 11 Bipolar Stepping 0.67A 17oz.in\/12Ncm 1.8deg 4 Leads\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eThis hybrid bipolar stepper motor with 1.8 deg. step angle (200\nsteps\/revolution). Each phase draws 670 mA at 6.2 V, allowing for a holding\ntorque of 12Ncm(17oz-in). Planetary Gearbox is available for this model.\nElectrical Specification: Manufacturer Part Number: 11HS20-0674S Motor\nType: Bipolar Stepper Step Angle: 1.8 deg. Holding Torque: 12Ncm(17oz-in)\n Rated Current\/phase: 0.67A Phase Resistance: 9.2ohms Inductance:\n5.7mH+\/-20%(1KHz) Physical Specification: Frame Size: 28 x 28mm Body\nLength: 51mm Shaft Diameter: 5mm Shaft Length: 20mm D-cut Length: 15mm \nNumber of Leads: 4 Lead Length: 500mm Weight: 190g Connection: Black(A+),\nGreen(A-), Red(B+), Blue(B-) Warning: Make sure the motor connect to a\nconstant current or chopper drive controller before you test motor. Connecting\nthe motor directly to a power supply will destroy the motor.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eNEMA 11 Hybrid bipolar stepper motor, 12Ncm(17oz-in) holding torque\u003c\/li\u003e\n \u003cli\u003eFrame Size 28 x 28mm, Body Length 51mm\u003c\/li\u003e\n \u003cli\u003e4-wires (Black, Green, Blue, Red)\u003c\/li\u003e\n \u003cli\u003eRated current 0.67A ,Step Angle 1.8, resistance 9.2ohms\u003c\/li\u003e\n \u003cli\u003eShaft Diameter 5mm , Shaft Length 20mm\u003c\/li\u003e\n \u003c\/ul\u003e"}
