{"id":9681046372503,"title":"STEPPERONLINE Nema 17 Stepper Motor L=39mm Gear Ratio 10:1 30arcmin MG Series Planetary Gearbox","handle":"stepperonline-nema-17-stepper-motor-l-39mm-gear-ratio-10-1-30arcmin-mg-series-planetary-gearbox","description":"\u003ch3\u003eSTEPPERONLINE Nema 17 Stepper Motor L=39mm Gear Ratio 10:1 30arcmin MG Series Planetary Gearbox\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eElectrical Specification Part Number: 17HS15-1584S-MG10 Motor Type: Bipolar\nStepper Holding Torque without Gearbox: 36Ncm(51.0oz.in) Rated\nCurrent\/phase: 1.58A Phase Resistance: 1.65ohms Inductance: 3.2mH±20%(1KHz)\nInsulation Class: B 130°C[266°F] Gearbox Specifications Gearbox Type: Spur\nPlanetary Gear Material: Powder Metallurgy Gear Ratio: 10:1 Efficiency: 90%\nBacklash at No-load:≤30arcmin Max.Permissible Torque: 5Nm(44.25lb-in)\nNoise: ≤55dB Waterproof Rating: IP54 Lifetime: 20000hours Physical\nSpecification Frame Size: 42 x 42mm Motor Length: 39mm Gearbox Length: 40mm\nOutput Shaft Type: Key way Output Shaft Diameter: Φ8mm Output Shaft Length:\n21.5mm Connection A+: Black, A-: Green, B+: Red, B-: Blue\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHigh torque, Low noise\u003c\/li\u003e\n \u003cli\u003eThe gear ratio is 10:1 and the Max. backlash is 30 arc minutes.\u003c\/li\u003e\n \u003cli\u003eIt's an excellent choice for applications that require good accuracy but low cost.\u003c\/li\u003e\n \u003cli\u003eAs MG series gearbox built-in shaft coupling, so you can change the motor or gearbox easily.\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2026-07-30T18:26:23+10:00","created_at":"2026-07-26T20:49:45+10:00","vendor":"STEPPERONLINE","type":"3D Printer Motors","tags":["home_improvement_Aug2026"],"price":21400,"price_min":21400,"price_max":21400,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48068260888727,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0F4CKD1VC","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"STEPPERONLINE Nema 17 Stepper Motor L=39mm Gear Ratio 10:1 30arcmin MG Series Planetary Gearbox","public_title":null,"options":["Default Title"],"price":21400,"weight":530,"compare_at_price":null,"inventory_management":"shopify","barcode":"17HS15-1584S-MG10","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/newnestshop.com\/cdn\/shop\/files\/B0F4CKD1VC.jpg?v=1785062987","\/\/newnestshop.com\/cdn\/shop\/files\/51MRYYrTYyL.jpg?v=1785062987","\/\/newnestshop.com\/cdn\/shop\/files\/519xi0gFRyL.jpg?v=1785062987","\/\/newnestshop.com\/cdn\/shop\/files\/51QJiWAbmqL.jpg?v=1785062987","\/\/newnestshop.com\/cdn\/shop\/files\/510YneRe_ML.jpg?v=1785062987","\/\/newnestshop.com\/cdn\/shop\/files\/51DRsAqktdL.jpg?v=1785062987"],"featured_image":"\/\/newnestshop.com\/cdn\/shop\/files\/B0F4CKD1VC.jpg?v=1785062987","options":["Title"],"media":[{"alt":null,"id":42456770805911,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/B0F4CKD1VC.jpg?v=1785062987"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/B0F4CKD1VC.jpg?v=1785062987","width":1000},{"alt":null,"id":42456770838679,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51MRYYrTYyL.jpg?v=1785062987"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51MRYYrTYyL.jpg?v=1785062987","width":1000},{"alt":null,"id":42456770871447,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/519xi0gFRyL.jpg?v=1785062987"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/519xi0gFRyL.jpg?v=1785062987","width":1000},{"alt":null,"id":42456770904215,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51QJiWAbmqL.jpg?v=1785062987"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51QJiWAbmqL.jpg?v=1785062987","width":1000},{"alt":null,"id":42456770936983,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/510YneRe_ML.jpg?v=1785062987"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/510YneRe_ML.jpg?v=1785062987","width":1000},{"alt":null,"id":42456770969751,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/newnestshop.com\/cdn\/shop\/files\/51DRsAqktdL.jpg?v=1785062987"},"aspect_ratio":1.0,"height":1000,"media_type":"image","src":"\/\/newnestshop.com\/cdn\/shop\/files\/51DRsAqktdL.jpg?v=1785062987","width":1000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eSTEPPERONLINE Nema 17 Stepper Motor L=39mm Gear Ratio 10:1 30arcmin MG Series Planetary Gearbox\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eElectrical Specification Part Number: 17HS15-1584S-MG10 Motor Type: Bipolar\nStepper Holding Torque without Gearbox: 36Ncm(51.0oz.in) Rated\nCurrent\/phase: 1.58A Phase Resistance: 1.65ohms Inductance: 3.2mH±20%(1KHz)\nInsulation Class: B 130°C[266°F] Gearbox Specifications Gearbox Type: Spur\nPlanetary Gear Material: Powder Metallurgy Gear Ratio: 10:1 Efficiency: 90%\nBacklash at No-load:≤30arcmin Max.Permissible Torque: 5Nm(44.25lb-in)\nNoise: ≤55dB Waterproof Rating: IP54 Lifetime: 20000hours Physical\nSpecification Frame Size: 42 x 42mm Motor Length: 39mm Gearbox Length: 40mm\nOutput Shaft Type: Key way Output Shaft Diameter: Φ8mm Output Shaft Length:\n21.5mm Connection A+: Black, A-: Green, B+: Red, B-: Blue\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eHigh torque, Low noise\u003c\/li\u003e\n \u003cli\u003eThe gear ratio is 10:1 and the Max. backlash is 30 arc minutes.\u003c\/li\u003e\n \u003cli\u003eIt's an excellent choice for applications that require good accuracy but low cost.\u003c\/li\u003e\n \u003cli\u003eAs MG series gearbox built-in shaft coupling, so you can change the motor or gearbox easily.\u003c\/li\u003e\n \u003c\/ul\u003e"}
